DX-10PV
-
The Northstar DX-PV series represents the absolute best value for the customer who demands a heavy-duty professional grade two post lift at the lowest possible price. Northstar has been manufacturing the PV series with two posts above ground lifts for over a decade.
The commercial grade Northstar DX-10PV two post lift includes some modifications and improvements that make it one of the most popular above ground lifts in the world.This lift is the perfect choice for use in a large commercial service department or a homeowner. The Northstar DX-10PV is designed and engineered to safely lift (and work on) everything from a Smart Car® to a one-ton diesel dually.
Features and Benefits
- Model: DX-10PV
- 10,000 lb. capacity
- Commercial Grade
- Asymmetric/Symmetric Arms
- Automatic Arm Restraints
- “Padded” Shut-Off Bar
- Thick Rubber Covers on Carriages
- Single Point Lock Release
- Direct-Drive Cylinders
- Powder Coat Finish
- Adjustable Height – 11 11 1/8″ or 12 3″
- Free 12 Piece Truck Adapter Set
- Mounting Hardware Included
- Shipping Weight: 1875 lbs.
- 5 Year Structural Warranty/2 Year Hydraulic Warranty – Parts only
Introduction
The Northstar DX-PV series represents the absolute best value for the customer who demands a heavy-duty professional grade two post lift at the lowest possible price. Northstar has been manufacturing the PV series with two posts above ground lifts for over a decade.
The commercial grade Northstar DX-10PV two post lift includes some modifications and improvements that make it one of the most popular above ground lifts in the world.
This lift is the perfect choice for use in a large commercial service department or a homeowner. The Northstar DX-10PV is designed and engineered to safely lift (and work on) everything from a Smart Car® to a one-ton diesel dually.
NorthStar DX-10PV Specifications
- Capacity: 10000 lbs.
- Overall Height: 143 1/8″ (11 11 1/8″) or 147″ (12 3″)
- Overall Floor Width: 137 1/2″ (11 5 1/2″)
- Outside Columns: 125 1/2″ (10 5 1/2”)
- Inside Column Width: 110 1/8″ (9 2 1/8″)
- Drive Thru clearance: 90 1/4″ Asymmetric/ 96 1/4″ Symmetric
- Max. Lift height w/o Adapters: 72 1/2″
- Max. Lift height w/ Adapters: 81 1/4″
- Min. Arm height: 4 1/2″
- Column Size: 7 1/2″ x 14 1/2″
- Base of Column: 17 1/2″ x 20 1/2″
- Column Steel Thickness: 6mm
- Arm Steel Thickness: 6mm
- Motor/Electrical Requirement: 220-volt, single phase, 30-amp breaker required
- Oil Requirement: 3-5 Gallons AW32 or AW46 (NOT INCLUDED)
- Shipping Weight: 1,875 lbs.
- Adapter Heights: 4 Each 1.25″, 2.5″, 5″
- Arm Hole/Adapter Peg Size: 1.5″
